3DACMT-1 – 3-Axis AC Magnetic Transducer

  • Frequency range 10kHz – 200kHz
  • Magnetic field resolution better than 1.5μTrms
  • Small probe volume of about 3.6 cm3
  • Non-invasive: The probe does not modify the measured magnetic field
  • Highly linear response
  • High transduction accuracy of ±1%
  • High phase accuracy: <3° at 85kHz
  • Excellent angular accuracy <±1°
  • Negligible cross-talk
  • Common center of coils for all three axis
  • Insensitive to electrical fields or capacitive coupling
  • Analog output

Add to Inquiry

TYPICAL APPLICATIONS

Mapping of wireless charges for electric and hybrid electric vehicles
